822-06-0 structure, C8H12N2O2
hexamethylene diisocyanate
CAS No.: 822-06-0 Formula: C8H12N2O2 Molecular Weight: 168.19300
Search Suppliers

hexamethylene diisocyanate

CAS No.:

822-06-0

Formula:

C8H12N2O2

Molecular Weight: 168.19300
Suppliers: All (35) China Suppliers (35) Price Available (9) Contractor (1)

Description

Hexamethylene diisocyanate (HDI) is an organic compound in the class known as isocyanates. More specifically, it is an aliphatic diisocyanate. It is produced in relatively small quantities, accounting for (with isophorone diisocyanate) only 3.4% of the global diisocyanate market in the year 2000. Aliphatic diisocyanates are used in special applications, such as enamel coatings which are resistant to abrasion and degradation from ultraviolet light. These properties are particularly desirable in, for instance, the exterior paint applied to aircraft.

Numbering system

MDL number MFCD00002047
EINECS number 212-485-8

Properties

Appearance & Physical State

Clear liquid

Density

1.04

Boiling Point

255ºC

Melting Point

-55ºC

Flash Point

140ºC

Refractive Index

1.451-1.453

Water Solubility

Reacts

Stability

Stable. Moisture sensitive. Combustible. Incompatible with strong oxidizing agents, strong bases, amines, acids. May react explosively with alcohols in the presence of base without a diluting solvent. Heating above 200ºC may cause polymerization.

Storage Condition

2-8ºC

Vapor Pressure

0.05 mm Hg ( 25 °C)

Safety Info

RTECS

MO1740000

Hazard Class

6.1

Safety Statements

S26-S28-S38-S45

HS Code

2929104000

Packing Group

II

WGK Germany

1

RIDADR

UN 2281

Risk Statements

R23; R36/37/38; R42/43

Hazard Codes

T

Caution Statement

P260; P280; P284; P303 + P361 + P353; P304 + P340 + P310; P305 + P351 + P338

Symbol

GHS05, GHS06, GHS08

Signal Word

Danger

Hazard Declaration

H302; H314; H317; H330; H334

SDS 1.0

Expand

SDS 1.0

Collapse
Download/Modify | Technical supported by XiXisys.com. For US version, EU version (23 languages) and more, please refer to xixisys.com/en/sds/search

SAFETY DATA SHEETS

According to Globally Harmonized System of Classification and Labelling of Chemicals (GHS) - Sixth revised edition

Version: 1.0

Creation Date: Aug 12, 2017

Revision Date: Aug 12, 2017

1.Identification

1.1 GHS Product identifier

Product name hexamethylene diisocyanate

1.2 Other means of identification

Product number -
Other names hexamethylene-1,6-diisocyanate

1.3 Recommended use of the chemical and restrictions on use

Identified uses For industry use only. One of the main uses of hexamethylene diisocyanate is as a polymerizing agent in polyurethane spray paint formulations and coatings (e.g., automobile paint). Hexamethylene diisocyanate is used in the preparation of dental materials, contact lenses, and medical adsorbents.
Uses advised against no data available

1.4 Supplier's details

Company MOLBASE (Shanghai) Biotechnology Co., Ltd.
Address Floor 4 & 5, Building 12, No. 1001 North Qinzhou Road,
Xuhui District, Shanghai, China
Telephone +86(21)64956998
Fax +86(21)54365166

1.5 Emergency phone number

Emergency phone number +86-400-6021-666
Service hours Monday to Friday, 9am-5pm (Standard time zone: UTC/GMT +8 hours).

2.Hazard identification

2.1 Classification of the substance or mixture

Skin irritation, Category 2

Eye irritation, Category 2

Skin sensitization, Category 1

Acute toxicity - Inhalation, Category 3

Specific target organ toxicity – single exposure, Category 3

Respiratory sensitization, Category 1

2.2 GHS label elements, including precautionary statements

Pictogram(s)
Signal word

Danger

Hazard statement(s)

H315 Causes skin irritation

H319 Causes serious eye irritation

H317 May cause an allergic skin reaction

H331 Toxic if inhaled

H335 May cause respiratory irritation

H334 May cause allergy or asthma symptoms or breathing difficulties if inhaled

Precautionary statement(s)
Prevention

P264 Wash ... thoroughly after handling.

P280 Wear protective gloves/protective clothing/eye protection/face protection.

P261 Avoid breathing dust/fume/gas/mist/vapours/spray.

P272 Contaminated work clothing should not be allowed out of the workplace.

P271 Use only outdoors or in a well-ventilated area.

P284 [In case of inadequate ventilation] wear respiratory protection.

Response

P302+P352 IF ON SKIN: Wash with plenty of water/...

P321 Specific treatment (see ... on this label).

P332+P313 If skin irritation occurs: Get medical advice/attention.

P362+P364 Take off contaminated clothing and wash it before reuse.

P305+P351+P338 IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing.

P337+P313 If eye irritation persists: Get medical advice/attention.

P333+P313 If skin irritation or rash occurs: Get medical advice/attention.

P304+P340 IF INHALED: Remove person to fresh air and keep comfortable for breathing.

P311 Call a POISON CENTER/doctor/…

P312 Call a POISON CENTER/doctor/…if you feel unwell.

P342+P311 If experiencing respiratory symptoms: Call a POISON CENTER/doctor/...

Storage

P403+P233 Store in a well-ventilated place. Keep container tightly closed.

P405 Store locked up.

Disposal

P501 Dispose of contents/container to ...

2.3 Other hazards which do not result in classification

none

3.Composition/information on ingredients

3.1 Substances

Chemical name Common names and synonyms CAS number EC number Concentration
hexamethylene diisocyanate hexamethylene diisocyanate 822-06-0 none 100%

4.First-aid measures

4.1 Description of necessary first-aid measures

General advice

Consult a physician. Show this safety data sheet to the doctor in attendance.

If inhaled

Fresh air, rest. Artificial respiration may be needed. Refer for medical attention.

In case of skin contact

Remove contaminated clothes. Rinse skin with plenty of water or shower. Refer for medical attention .

In case of eye contact

First rinse with plenty of water for several minutes (remove contact lenses if easily possible), then refer for medical attention.

If swallowed

Rinse mouth. Refer for medical attention .

4.2 Most important symptoms/effects, acute and delayed

Excerpt from ERG Guide 156 [Substances - Toxic and/or Corrosive (Combustible / Water-Sensitive)]: TOXIC; inhalation, ingestion or contact (skin, eyes) with vapors, dusts or substance may cause severe injury, burns or death. Contact with molten substance may cause severe burns to skin and eyes. Reaction with water or moist air will release toxic, corrosive or flammable gases. Reaction with water may generate much heat that will increase the concentration of fumes in the air. Fire will produce irritating, corrosive and/or toxic gases. Runoff from fire control or dilution water may be corrosive and/or toxic and cause pollution. (ERG, 2016)

4.3 Indication of immediate medical attention and special treatment needed, if necessary

Immediate first aid: Ensure that adequate decontamination has been carried out. If patient is not breathing, start artificial respiration, preferably with a demand-valve resuscitator, bag-valve-mask device, or pocket mask, as trained. Perform CPR as necessary. Immediately flush contaminated eyes with gently flowing water. Do not induce vomiting. If vomiting occurs, lean patient forward or place on left side (head-down position, if possible) to maintain an open airway and prevent aspiration. Keep patient quiet and maintain normal body temperature. Obtain medical attention. /Isocyanates, aliphatic thiocyanates, and related compounds/

5.Fire-fighting measures

5.1 Extinguishing media

Suitable extinguishing media

If material on fire or involved in fire: Extinguish fire using agent suitable for type of surrounding fire. (Material itself does not bur or burns with difficulty.) use water in flooding quantities as fog. Use foam, dry chemical, or carbon dioxide. Keep run-off water out of sewers and water sources.

5.2 Specific hazards arising from the chemical

Excerpt from ERG Guide 156 [Substances - Toxic and/or Corrosive (Combustible / Water-Sensitive)]: Combustible material: may burn but does not ignite readily. Substance will react with water (some violently) releasing flammable, toxic or corrosive gases and runoff. When heated, vapors may form explosive mixtures with air: indoors, outdoors and sewers explosion hazards. Most vapors are heavier than air. They will spread along ground and collect in low or confined areas (sewers, basements, tanks). Vapors may travel to source of ignition and flash back. Contact with metals may evolve flammable hydrogen gas. Containers may explode when heated or if contaminated with water. (ERG, 2016)

5.3 Special protective actions for fire-fighters

Wear self-contained breathing apparatus for firefighting if necessary.

6.Accidental release measures

6.1 Personal precautions, protective equipment and emergency procedures

Use personal protective equipment. Avoid dust formation. Avoid breathing vapours, mist or gas. Ensure adequate ventilation. Evacuate personnel to safe areas. Avoid breathing dust. For personal protection see section 8.

6.2 Environmental precautions

Evacuate danger area! Consult an expert! Personal protection: complete protective clothing including self-contained breathing apparatus. Ventilation. Collect leaking and spilled liquid in sealable containers as far as possible. Absorb remaining liquid in sand or inert absorbent. Then store and dispose of according to local regulations.

6.3 Methods and materials for containment and cleaning up

Environmental considerations: Air spill: Apply water spray or mist to knock down vapors.

7.Handling and storage

7.1 Precautions for safe handling

Avoid contact with skin and eyes. Avoid formation of dust and aerosols. Avoid exposure - obtain special instructions before use.Provide appropriate exhaust ventilation at places where dust is formed. For precautions see section 2.2.

7.2 Conditions for safe storage, including any incompatibilities

Separated from incompatible materials and food and feedstuffs. See Chemical Dangers. Cool. Dry. Keep in the dark. Ventilation along the floor.Isocyanates are transported in railroad tank cars, tank trucks, tanks in ships, containers, and drums. They are stored in steel tanks and processed in steel equipment. For long-term storage stainless steel is recommended. To avoid contamination by atmospheric moisture, a dry air or inert gas blanket is essential. /Isocyanates/

8.Exposure controls/personal protection

8.1 Control parameters

Occupational Exposure limit values

Recommended Exposure Limit: 10 Hour Time-Weighted Average: 0.005 ppm (0.035 ug/cu m)

Recommended Exposure Limit: 10 Minute Ceiling Value: 0.020 ppm (0.140 ug/cu m).

Biological limit values

no data available

8.2 Appropriate engineering controls

Handle in accordance with good industrial hygiene and safety practice. Wash hands before breaks and at the end of workday.

8.3 Individual protection measures, such as personal protective equipment (PPE)

Eye/face protection

Safety glasses with side-shields conforming to EN166. Use equipment for eye protection tested and approved under appropriate government standards such as NIOSH (US) or EN 166(EU).

Skin protection

Wear impervious clothing. The type of protective equipment must be selected according to the concentration and amount of the dangerous substance at the specific workplace. Handle with gloves. Gloves must be inspected prior to use. Use proper glove removal technique(without touching glove's outer surface) to avoid skin contact with this product. Dispose of contaminated gloves after use in accordance with applicable laws and good laboratory practices. Wash and dry hands. The selected protective gloves have to satisfy the specifications of EU Directive 89/686/EEC and the standard EN 374 derived from it.

Respiratory protection

Wear dust mask when handling large quantities.

Thermal hazards

no data available

9.Physical and chemical properties

Physical state Clear liquid
Colour Liquid
Odour Sharp, pungent odor
Melting point/ freezing point -46°C(lit.)
Boiling point or initial boiling point and boiling range 82-85°C/0.1mmHg
Flammability Class IIIB Combustible Liquid: Fl.P. at or above 93.33°C.Combustible. Gives off irritating or toxic fumes (or gases) in a fire.
Lower and upper explosion limit / flammability limit no data available
Flash point 135°C
Auto-ignition temperature 454°C
Decomposition temperature no data available
pH no data available
Kinematic viscosity no data available
Solubility In water:Reacts
Partition coefficient n-octanol/water (log value) log Kow = 3.20 (est)
Vapour pressure 0.05 mm Hg ( 25 °C)
Density and/or relative density 1.047g/mLat 20°C(lit.)
Relative vapour density 5.81 (Air = 1)
Particle characteristics no data available

10.Stability and reactivity

10.1 Reactivity

no data available

10.2 Chemical stability

Stable under recommended storage conditions.

10.3 Possibility of hazardous reactions

HEXAMETHYLENE DIISOCYANATE reacts with water. Base-catalyzed reactions of this compound with alcohols may be explosively violent in the absence of diluting solvents. This chemical is incompatible with strong bases, amines, acids and strong oxidizers. It is also incompatible with metal compounds and surface active materials. .

10.4 Conditions to avoid

no data available

10.5 Incompatible materials

Base-catalyzed reactions of isocyanates such as hexamethylene diisocyanate with alcohols should generally be carried out in inert solvents. Such reactions in the absence of solvents often occur with explosive violence.

10.6 Hazardous decomposition products

When heated to decomposition it emits toxic fumes of /nitrogen oxides/.

11.Toxicological information

Acute toxicity

  • Oral: LD50 Mouse oral 350 mg/kg
  • Inhalation: LC50 Rat (male) inhalation 40 ppm/1 hr.
  • Dermal: no data available

Skin corrosion/irritation

no data available

Serious eye damage/irritation

no data available

Respiratory or skin sensitization

no data available

Germ cell mutagenicity

no data available

Carcinogenicity

no data available

Reproductive toxicity

No information is available on the reproductive or developmental effects of hexamethylene diisocyanate in humans. There was no effect on male or female reproductive organs in one rat inhalation study.

STOT-single exposure

no data available

STOT-repeated exposure

no data available

Aspiration hazard

no data available

12.Ecological information

12.1 Toxicity

  • Toxicity to fish: no data available
  • Toxicity to daphnia and other aquatic invertebrates: no data available
  • Toxicity to algae: no data available
  • Toxicity to microorganisms: no data available

12.2 Persistence and degradability

no data available

12.3 Bioaccumulative potential

Hexamethylene diisocyanate reacts readily with water to form amines and polyureas(1-3); therefore, bioconcentration of monomeric hexamethylene diisocyanate in aquatic organisms is not expected to be an important environmental fate process(SRC).

12.4 Mobility in soil

Hexamethylene diisocyanate reacts readily with water to form amines and polyureas(1-3); therefore, adsorption of monomeric hexamethylene diisocyanate in soil is not expected to be an important environmental fate process(SRC).

12.5 Other adverse effects

no data available

13.Disposal considerations

13.1 Disposal methods

Product

The material can be disposed of by removal to a licensed chemical destruction plant or by controlled incineration with flue gas scrubbing. Do not contaminate water, foodstuffs, feed or seed by storage or disposal. Do not discharge to sewer systems.

Contaminated packaging

Containers can be triply rinsed (or equivalent) and offered for recycling or reconditioning. Alternatively, the packaging can be punctured to make it unusable for other purposes and then be disposed of in a sanitary landfill. Controlled incineration with flue gas scrubbing is possible for combustible packaging materials.

14.Transport information

14.1 UN Number

ADR/RID: UN2281 IMDG: UN2281 IATA: UN2281

14.2 UN Proper Shipping Name

ADR/RID: HEXAMETHYLENE- DIISOCYANATE
IMDG: HEXAMETHYLENE- DIISOCYANATE
IATA: HEXAMETHYLENE- DIISOCYANATE

14.3 Transport hazard class(es)

ADR/RID: 6.1 IMDG: 6.1 IATA: 6.1

14.4 Packing group, if applicable

ADR/RID: II IMDG: II IATA: II

14.5 Environmental hazards

ADR/RID: no IMDG: no IATA: no

14.6 Special precautions for user

no data available

14.7 Transport in bulk according to Annex II of MARPOL 73/78 and the IBC Code

no data available

15.Regulatory information

15.1 Safety, health and environmental regulations specific for the product in question

Chemical name Common names and synonyms CAS number EC number
hexamethylene diisocyanate hexamethylene diisocyanate 822-06-0 none
European Inventory of Existing Commercial Chemical Substances (EINECS) Listed.
EC Inventory Listed.
United States Toxic Substances Control Act (TSCA) Inventory Listed.
China Catalog of Hazardous chemicals 2015 Listed.
New Zealand Inventory of Chemicals (NZIoC) Listed.
Philippines Inventory of Chemicals and Chemical Substances (PICCS) Listed.
Vietnam National Chemical Inventory Listed.
Chinese Chemical Inventory of Existing Chemical Substances (China IECSC) Listed.

16.Other information

Information on revision

Creation Date Aug 12, 2017
Revision Date Aug 12, 2017

Abbreviations and acronyms

  • CAS: Chemical Abstracts Service
  • ADR: European Agreement concerning the International Carriage of Dangerous Goods by Road
  • RID: Regulation concerning the International Carriage of Dangerous Goods by Rail
  • IMDG: International Maritime Dangerous Goods
  • IATA: International Air Transportation Association
  • TWA: Time Weighted Average
  • STEL: Short term exposure limit
  • LC50: Lethal Concentration 50%
  • LD50: Lethal Dose 50%
  • EC50: Effective Concentration 50%

References

  • IPCS - The International Chemical Safety Cards (ICSC), website: http://www.ilo.org/dyn/icsc/showcard.home
  • HSDB - Hazardous Substances Data Bank, website: https://toxnet.nlm.nih.gov/newtoxnet/hsdb.htm
  • IARC - International Agency for Research on Cancer, website: http://www.iarc.fr/
  • eChemPortal - The Global Portal to Information on Chemical Substances by OECD, website: http://www.echemportal.org/echemportal/index?pageID=0&request_locale=en
  • CAMEO Chemicals, website: http://cameochemicals.noaa.gov/search/simple
  • ChemIDplus, website: http://chem.sis.nlm.nih.gov/chemidplus/chemidlite.jsp
  • ERG - Emergency Response Guidebook by U.S. Department of Transportation, website: http://www.phmsa.dot.gov/hazmat/library/erg
  • Germany GESTIS-database on hazard substance, website: http://www.dguv.de/ifa/gestis/gestis-stoffdatenbank/index-2.jsp
  • ECHA - European Chemicals Agency, website: https://echa.europa.eu/

Disclaimer: The above information is believed to be correct but does not purport to be all inclusive and shall be used only as a guide. The information in this document is based on the present state of our knowledge and is applicable to the product with regard to appropriate safety precautions. It does not represent any guarantee of the properties of the product. We as supplier shall not be held liable for any damage resulting from handling or from contact with the above product.

MSDS

Expand
1H NMR : PredictExpand

NMR Spectrum 1H NMR : Predict

Collapse
822-06-0 NMR spectrum
More
Exposure Route Type of Test Species Observed Dose/Duration Toxic Effects
Oral LD50 - Lethal dose, 50 percent kill Rodent - rat 710 uL/kg 1.Details of toxic effects not reported other than lethal dose value
Inhalation LCLo - Lowest published lethal concentration Rodent - rat 60 mg/m3/4H 1.Sense Organs and Special Senses (Eye)-lacrimation
2.Lungs, Thorax, or Respiration-dyspnea
3.Nutritional and Gross Metabolic-weight loss or decreased weight gain
Oral LD50 - Lethal dose, 50 percent kill Rodent - mouse 350 mg/kg 1.Details of toxic effects not reported other than lethal dose value
Recommended Suppliers
More Suppliers>>
Other items you might be interested in
Category in MOLBASE
